Printheads
Replacing the Printhead
Follow the steps below to replace the Printhead. Failure to follow this procedure may cause ink leak from
the Printhead, which may cause stains.
Note
• Prepare a new Ink Tank when ink levels are low.
• Your hands may become dirty during Printhead replacement. Use the gloves provided with the new
Printhead for replacement.
• Choose On in Auto Print to have the printer automatically adjust the Printhead alignment after
replacement of the Printhead. (→P.55)
1. If the roll is not ejected because of the cutting method selected, cut it manually and remove it.
(→P.342)
2. Clean inside the Top Cover. (→P.495)
3.
Press the Menu button to display MAIN MENU.
4. Press ▲ or ▼ to select Maintenance, and then press the ► button.
5.
Press ▲ or ▼ to select Replace P.head, and then press the ► button.
6.
Press ▲ or ▼ to select Yes, and then press the OK button.
Ink is now lled.
After about three minutes, a message is shown on the Display Screen instructing you to open
the Top Cover.
7.
Open the Top Cover.
Instructions are now shown on the Display Screen regarding Printhead replacement.
