49
This section describes multiple flash
shooting where slave C is added to flash
tubes A and B.
1 Set the flash mode to < a>.
Press the < E> button and set to
< a>.
2 Set < l> and <6>.
Press the < ,> button to display
< ^>, , and
<
6>.
Check that < :> and < M
>
are displayed.
3 Check the transmission channel.
If the channels of the master unit and
slave unit are different, set them to
the same number (p.48).
4 Set slave C and position it.
Set the firing group of the slave unit to
C, and position the unit within the
range shown on page 44.
a: Multiple Flash Shooting with Slave C Added
