15
Attaching the Control Unit to the Camera
1
Attach the control unit.
Slip the control unit’s mounting foot
all the way into the camera’s hot
shoe.
2
Secure the control unit.
Slide the mounting foot lock lever to
the right.
X
When the lock lever clicks in place, it
is locked.
3
Detach the control unit.
While pressing the lock-release
button, slide the lock lever to the left
and detach the control unit.
Attaching the Control Unit to the Camera
When <
!> is displayed, or the LCD panel display turns off during
recycling, replace the batteries with new ones.
Use a new set of four batteries of the same brand. When replacing the
batteries, replace all four at one time.
AA/LR6 Ni-MH or lithium batteries can also be used.
Be sure to turn off the MR-14EX II before attaching or detaching it.
