l Setting the Flash RatioN
Set <
4> or <5>.
Press the <
,> button to display
<
_> and <4> or
<
_> and <5>.
Single-side Firing
Flash tube
B only
Flash tube
A only
Flash ratio control is not available on the models listed below. Both sides will
fire at the same flash output, or single-side firing will apply.
EOS Elan II/Elan II E/50/50E, EOS REBEL XS N/REBEL G II/3000N/66,
EOS REBEL 2000/300, EOS REBEL G/500N, EOS IX, EOS IX Lite/IX 7
The flash ratio of 8:1 to 1:1 to 1:8 is equivalent to 3:1 to 1:1 to 1:3 (1/2-
stop increments) when converted to the number of f/stops.
The details of the flash ratio settings are as follows.
When <
l>, <4>, or <5> is not displayed, flash tubes
A and B will fire at the same flash output.
When the flash mode is set to , see pages 32-34.
