51
ESC i V 2D bar code (PDF417)
[ASCII] ESC i V data
[Decimal] 27 105 86 data
[Hexadecimal] 1B 69 56 data
・ Format
ESC i V [parameters] [bar code data] \\\
① ② ③
① Parameters
Unlike with 1D bar codes, all parameters must be specified in order, starting from the
top.
If a value other than those listed is entered for a parameter, that parameter is set to its
default value.
1. Cell size
[1-byte decimal] 4
[1-byte decimal] 6
[1-byte decimal] 8
[1-byte decimal] 10
[1-byte decimal] 12 Specifies the dot size per cell side.
Prints 4 dots per cell side. (default value)
Prints 6 dots per cell side.
Prints 8 dots per cell side.
Prints 10 dots per cell side.
Prints 12 dots per cell side.
2. Symbol type
[1-byte decimal] 0
[1-byte decimal] 1
[1-byte decimal] 2
[1-byte decimal] 3
Standard (default value)
Truncated
Micro PDF417 standard
Micro PDF417 CODE128 emulation
3. Data input method
[1-byte decimal] 0
[1-byte decimal] 1
Auto input (default value)
Binary input
4. Error correction
capacity–type
[1-byte decimal] 0
[1-byte decimal] 1
Level input (default value)
Percentage input
5. Error correction
capacity–value
When level input is
selected:
[2-byte decimal] 0 to 8
When percentage input is
selected:
[2-byte decimal] 0 to 400
Level input (default value of 0)
Percentage input (default value of 0)
6. Symbol size in X
direction
[1-byte decimal] 0
[1-byte decimal] 1 to 30
Auto setting (default value)
Manual setting
