Brother PT-9500PC - Manual (Page 305)

70
Layout window
When P-touch Editor is started up, a dialog box
appears, allowing you to select the initial layout
method.
1
Select the layout.
2
Click [OK].
→The Layout window appears.
■ Property dock
Click each button in the property dock to
display the property box for setting the font,
layout, etc. Click the button again to close
the property box.
† Print properties
Set the label printing method, printer and
number of copies.
† Page properties
Set the label size, margins, and orientation.
† Text properties
Set the font, font size, text alignment and
spacing, and line spacing.
† Layout properties
Set the graphic or text alignment and
rotation.
■ Draw toolbar
Tools for drawing shapes.
