6. Cancelling Programmes
Any ON/OFF programme can be cancelled by clearing its ON and OFF time.
Follow step 5 and when into the ON or OFF programme to be cancelled press
the button until the hour digits show --:
then press the button to clear the
programme. The display will show the hour and
minute digits and ON or OFF flashing.
(Note: Monday shown as an example of days set).
Self Cancelling Override
To change the output status from ON to OFF or vice versa during normal operation
press the button. The output status will change and indicate override is in
operation by flashing.
1 2 3 4 5 6 7
●
Specifications
1. Confirms to latest directives.
2. Contacts:
Silver Cadmium Oxide. Single pole change over.
3. Permissible Loads: 16A Resistive
6A At 0.4 power factor inductive
10A Filament lamps
*500W Fluorescent lighting with or without power factor
correction capacitors (4μF per 65W tube)
1 h.p. Motor
For other loads refer to Technical Service on 020 8450 0515
*This load with power factor correction capacitors is not
recommended for normally closed contacts.
4. Panel Cut Out: 67mm square with 2.5mm radius corners.
5. Battery Back-up: 1000 hours by factory fitted rechargeable battery.
6. Operating ambient temperature: -10°C to 40°C. Upper limit can be
increased for loads less than 16A –
refer to Technical Service.
7. Operating Voltage: 220 – 240V AC 50Hz.
