Timeguard PB05 - Manual

HELPLINE
020-8450-0515
Designed and manufactured in the U.K. 67.058.29(2)
5 6
OPERA
TING
INSTRUCTIONS
Specifications
● Supply Voltage: 220 - 240V 50Hz
● Ambient Temperature Range: -10° to 40°C
● Contacts: Silver Cadmium Dioxide
Single Pole Changeover
● Permissible Loads: 16A resistive
6A at 0.4 power factor inductive
10A filament lamps
500W* fluorescent lighting with
or without power factor correction
capacitors (4¨µF per 65W tube)
1hp motor
● EC Directives**: Conforms to 73/23/EEC
89/336/EEC
*Note: This load with power factor correction capacitors is not recommended for normally closed contacts.
**Note: When correctly incorporated into parent product/installation.
For other loads refer to techincal service on 020 8450 0515
Contacts 1 to 5
0.25mm blade connectors for mains and load connections
to PCB.
Contact Description
1 Normally Open Contact
2 Common Contact
3 Normally Closed Contact
4 Neutral
5 Live
Interconnection
For a product brochure please contact:
Timeguard Ltd. Victory Park, 400 Edgware Road,
London NW2 6ND Tel: 020-8452-1112
or email [email protected]
A Group company
P A N E L M A S T E R
P O W E R / R E L A Y P C B
Cat No. PB05
