Command Reference 35
Analog Outputs (continued)
Syntax Function
Ana2.param[=i][?]
Parameter to track with analog output #2
Ana2.paramMin[=n][?] Min Value
Ana2.paramMax[=n][?] Max Value
Ana2.OutMin[=n][?] Min Voltage
Ana2.OutMax[=n][?] Max Voltage
Ana2.calGain[=n][?] Gain calibration factor for D/A converter
Ana2.calZero[=n][?] Zero calibration factor for D/A converter
Ana2.output=n Use to set analog output when calibrating D/A
converter. Automatically sets Ana2.hold=1. You
must send Ana2.hold=0 when finished with
calibration.
Ana2.hold[=i][?] 1 ÆCalibration mode. Analog output is set with the
command Ana2.output=n.
0
ÆNormal mode. Analog output tracks the
parameter set with Ana2.param=i.
SaveCfg=973 Save these and other configuration parameters
Mirror Temperature Calibration Coefficients
Syntax Function
MirrorTempCal.r0[=n][?]
Callendar VanDusen R0 coefficient, ~ 100.00
MirrorTempCal.a[=n][?] Callendar VanDusen A coefficient, ~ 3.9083e-3
MirrorTempCal.b[=n][?] Callendar VanDusen B coefficient, ~ –5.775e-7
MirrorTempCal.c[=n][?] Callendar VanDusen C coefficient, ~ -4.183e-12
MirrorTempCal.avg[=n][?] Amount of averaging applied to measurement, ~40
MirrorTempCal.avgBand[=i][?] Only average when measurements remain within
this band, ~ 0.2 °C
MirrorTempCal.sensCode[=i][?] =42 for 385 RTD
MirrorTempCal.coefType[=i][?] =3 for Callendar VanDusen type coefficients
SaveCal=973 Save these and other calibration parameters
External Temperature Calibration Coefficients
Syntax Function
ExtTempCal.r0[=n][?]
Callendar VanDusen R0 coefficient, ~ 100.00
ExtTempCal.a[=n][?] Callendar VanDusen A coefficient, ~ 3.9083e-3
ExtTempCal.b[=n][?] Callendar VanDusen B coefficient, ~ –5.775e-7
ExtTempCal.c[=n][?] Callendar VanDusen C coefficient, ~ -4.183e-12
ExtTempCal.avg[=n][?] Amount of averaging applied to measurement, ~40
ExtTempCal.avgBand[=i][?] Only average when measurements remain within
this band, ~ 0.2 °C
ExtTempCal.sensCode[=i][?] =42 for 385 RTD
ExtTempCal.coefType[=i][?] =3 for Callendar VanDusen type coefficients
SaveCal=973 Save these and other calibration parameters
