Milestone LPR 1.0 - Manual (Page 24)

Milestone XProtect
®
LPR 1.0 Administrator's Manual
www.milestonesys.com 24 Events based on LPR
Events based on LPR
You can associate all types of events available in your XProtect Corporate or XProtect Enterprise with
a license plate list. However you must first create a license plate list (see "Add new license plate list"
on page 21). Do the following:
As soon as you have created a license plate list (see "Working with license plate lists" on page 21), it
becomes visible in the License Plate List and on the Lists tab of your LPR camera (see "Add new
LPR camera" on page 12).
1. In the License Plate List Information window (see "Manage license plate lists" on page 22),
by the Events triggered by list match selection field, click Select....
2. In the Select Events Triggered picker, select the required event.
3. If prompted, confirm to save changes.
4. The event is now associated with recognitions on the selected license plate list.
What happens when a system event is triggered? This is highly individual, as it depends entirely
upon the configuration of your system. In connection with LPR, triggered events are often used to
subsequently trigger output signals for raising of parking barriers, etc. However, triggered events can
also be used for making cameras record in high quality or similar. You can even use an event to
trigger combinations of such actions.
If you want to trigger an event if a license plate, which is not on a list, is recognized, you can use the
Unlisted License Plates list (see "About unlisted license plates list" on page 23).
