Milestone XProtect Analytics 2.2 – Generic VA; Administrator’s Manual
www.milestonesys.com Page 30 Event Mapping Tool
In the example, from we have selected a list of VIP vehicle
license plates.
2. In the Generic Events section’s Available events list, either ...
 Select Send alert text as event. This will send the
entire analytics detection alert text in the data packet
which the surveillance server will analyze in order to
trigger the generic event. If using this option, you
must be sure that the alert text contains the data matching the requirements of the
generic event configuration on the surveillance server.
- or -
 Use the Event text field to type the phrases or numbers required to trigger the
generic event. If more than phrase or number can be used for
triggering the generic event, type them on separate lines
(press your keyboard’s ENTER key for a new line). Example:
3. In the Server generic event port field, specify the port number on which the surveillance
server listens for generic event data. By default the port number is 1234. However, if the
port number has been changed on the surveillance server, make sure you match the
change in the Event Mapping Tool.
To verify which port is used for generic events on the surveillance server, open the
surveillance server’s Administrator application, click the I/O Setup button, then the
Advanced... button, and look for the port number in the Alert Port field.
4. Select the protocol on which the surveillance server listens for generic event data, either
TCP or UDP. Again, your selection must match what has been specified for the required
generic event on the surveillance server.
5. Optionally, you are able to send the data defined in step 2 to an additional host.
Why would I want to use an additional host? Sending data about analytics detections
to an additional host can be interesting in several scenarios, depending on your
organization’s needs. For example if you want to combine two or more analytics detections
in order to present them as one combined detection to users in the Smart Client. To
combine analytics detections you use the Event Proxy Tool, accessed by double-clicking the
file VideoOS.EventProxy.ProxySetup.exe in the XProtect Analytics installation folder, which
also contains documentation for the Event Proxy Tool. If using the Event Proxy Tool to
combine analytics detections, you would use the Event Mapping Tool’s Additional host fields
to specify the address, port and protocol on which the Event Proxy Tool listens for input.
Specify the address of the additional host in the Additional output host field, the required
port number in the Additional output port field, and the required protocol in the Additional
output event protocol field.
6. Save your event mapping by clicking the Save button in the Event Mapping Tool’s
toolbar.
Repeat if you want other analytics detections to trigger other generic events or sending of
data to additional hosts.
7. Open the XProtect Analytics Administrator application and restart the server service
by clicking the Restart Server button in the Administrator application’s toolbar.
Even if using this method locally, the localhost IP address 127.0.0.1 must be specified as a positive
IP address in the Generic VA Administrator application.
