MODEL CODES SRD960
Universal Positioner SRD960
010410
Version
Single Acting . . . . . . . . . . . . . . . . . . . . -B
Double Acting . . . . . . . . . . . . . . . . . . . -C
Position Transmitter (w/o pneumatic components) . -T
Local Control Panel (LCP960) For PST Monitoring . -L
Input / Communication
HART (4-20 mA) . . . . . . . . . . . . . . . . . (g)(p) . H
FoxCom (Digital) . . . . . . . . . . . . . . . . . (g)(p) . F
Profibus PA based on IEC 1158-2 (MBP)
according to FISCO (Fieldbus) . . . . . . . . . (g)()p . P
FOUNDATION Fieldbus H1 based on IEC 1158-2 (MBP)
according to FISCO (Fieldbus) . . . . . . . . . (g)(p) . Q
not applicable. . . . . . . . . . . . . . . . . . . . (f) . . X
Additional Inputs / Outputs
Without Additional Inputs / Outputs . . . . . . . . (n)(p) . . . . . N
Binary Input - integrated. . . . . . . . . . . . . . (g)(p) . . . . . B
Binary Output - integrated . . . . . . . . . . . . (g)(p) . . . . . P
Binary Inputs/Outputs (mandatory for ESD application) . . . . . . E
Analog Position Feedback (4-20 mA) . . . . . . . . . . . . . . . Q
- integrated and connected as Option Board . . . (g)(p)
- stand alone feedback unit . . . . . . . . . . . . (f)(p)
Potentiometer Input (for Remote Mounting - main unit)(g)(p) . . . . . D
Limit Switches (standard version SJ2-N) . . . . . (g)(p) . . . . . T
Limit Switches (security version SJ2-SN) . . . . . (g)(p) . . . . . U
Limit Switch (three-wire version) . . . . . . . . . (g)(p) . . . . . R
Mechanical Switches (Micro Switches) . . . . . . (g)(p) . . . . . V
Display / Indication
LEDs (cover without window and without external pushbuttons). . (p) . . S
Grafical LCD (cover with window and with external pushbuttons) . (g) . . D
LEDs (cover with window and with external pushbuttons) . . . . (g)(p). . L
Gauges
Without Gauges . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . S
Built-In Gauges with scale in bar/psi. . . . . . . . (g)(p) . . . . . . . . . . . . M
Pneumatical Connection
1/4 - 18 NPT . . . . . . . . . . . . . . . . . . . (g)(p) . . . . . . . . . . . . . . . . N
G 1/4 . . . . . . . . . . . . . . . . . . . . . . . (g)(p) . . . . . . . . . . . . . . . . G
not applicable . . . . . . . . . . . . . . . . . . . (f) . . . . . . . . . . . . . . . . . X
Electrical Connection
1/2 - 14 NPT (w/o cable glands or plugs for certified SRD960) . . . . . . . . . . . . . . . . . . 6
M20 x 1.5 (w/o cable glands or plugs for certified SRD960) . . . . . . . . . . . . . . . . . . . 7
Electrical Certification / Explosion protection
Flameproof II 2 G EEx d IIB/IIC T4/T5/T6 according to ATEX (w/o cable glands or plugs) . . . . . . . EDZ
Explosion-proof according to FM (w/o cable glands or plugs) . . . . . . . . . . (g)(p) . . . . . . . . FDZ
GOST Approved For Explosion-proof . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . GDZ
Without Ex (with cable glands and plugs). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ZZZ
Mounting Preparation on Positioner
NAMUR acc. to IEC 534-6 / Direct Mounting to Flowserve actuators FlowPak and FlowTop /
/ Rotary Actuators according to VDI/VDE 3845 . . . . . . . . . . . . . . . . . . . . . . . . (p) . . . . . . N
Rotary Actuators according to VDI/VDE 3845 . . . . . . . . . . . . . . . . . . . . . . . . . . (p) . . . . . . R
Integrated attachment with air channels on back / Rotary Actuators according to VDI/VDE 3845 (g)(p) . . . . . T
Direct mounting acc. to NAMUR VDI/VDE 3847 / Rotary Actuators according to VDI/VDE 3845(a)(g)(p). . . . . D
NAMUR acc. to IEC 534-6 / Rotary Actuators according to VDI/VDE 3845 . . . . . . . . . . . . . . . . . . . F
Language
LCD Language in English / German / French . . (e)(g)(p) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A
LCD Language in English / German / Spanish . . (e)(g)(p) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . B
LCD Language in English / German / Portuguese (e)(g)(p) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C
LCD Language in English / German / Polish . . . (e)(g)(p) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . D
LCD Language in English / German / Czech. . . (e)(g)(p) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E
LCD Language in English / German / Italian . . . (e)(g)(p) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . F
LCD Language in English / German / Turkish . . (e)(g)(p) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . G
LCD Language in English / German / Swedish. . (e)(g)(p) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . H
LCD Language in English / German / Finnish . . (e)(g)(p) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . J
LCD Language in English / German / Chinese . (a)(e)(g)(p) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . K
LCD Language in English / German / Russian . . (e)(g)(p) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . L
LCD Language in English / German / Hungarian. (e)(g)(p) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . M
LCD Language in English / German / Serbian . . (e)(g)(p) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . N
LCD Language in English / German / Dutch . . . (e)(g)(p) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . O
(continued on next page)
