Turbine Flow Sensor
Installation & Operating Instructions
03/12 Form No. 05-TUR-UM-00194 Page 7
Classic Flow Sensors
Material
Housing:
FSC, FSB 6013-T651 Anodized aluminum
FSD Stressproof® steel, zinc plated
Turbine Rotor: T416 Stainless steel
Rotor Supports:
FSC-375, 500, 750 C360 Brass
FSC-1000, 1005 6061-T6 Aluminum
FSD Tungsten carbide
Rotor Shaft:
FSC, FSB T303 Stainless steel
FSD Tungsten carbide
Bearings:
FSC, FSB 440 C Stainless steel ball bearings
FSD Tungsten carbide
Hub Cones:
FSC, FSB 6061-T6 Aluminum alloy
Retaining Rings:
FSC T303 Stainless steel
FSC-500, 750, 1000, 1005;
FSB; FSD Steel, zinc plate
Adapters/Plugs: 6061-T6 Anodized aluminum
Seals: Buna N standard
Viton® and EPR optional
Magnetic Pick-up:
Body T303 Stainless Steel
Nut T303 Stainless Steel
IFC (Intelligent Frequency Converter):
Body 6061-T6 Aluminum, nickel plate
Connector Brass, nickel plate
Ports:
SAE Straight thread O-ring boss, female, J1926/1;
Code 61 and Code 62: SAE J518
Dimensions See Appendix, page 16
Model Number Information
Performance
Flow Accuracy:
Standard Magnetic Pick-up ±1% of full scale
IFC Converter Option ±1% of reading @ 32 cSt
Repeatability: ±0.2%
Pressure Rating:
FSC, FSB 5000 PSI (345 Bar) maximum,
FSD 6000 PSI (414 Bar) maximum
Pressure Drop: See ∆ P charts on page 17
Turbine Response: ≤200 ms
Fluid Temperature: -4 to +300 °F (-20 to +150 °C)
Ambient Temperature: -4 to +131 °F (-20 to +55 °C)
Electrical
Magnetic Pick-up: Self-generating alternating pulse;
100 mV RMS (100 Hz) minimum.
FSC-375 only 10 mV RMS (200 Hz) minimum
IFC Converter: 4-20 mA 0-5 VDC
Power: Loop-powered, 6V 10-26 VDC
insertion loss max
10-30 VDC supply
Inputs: Mag pick-up Mag pick-up
Frequency 0-3500 Hz 0-3500 Hz
Trigger
Sensitivity 30 mV p-p 30 mV p-p
Freq Meas Accuracy ±1% ±1%
Analog Out: 4-20 mA current loop 0-5 VDC
Resolution 1:4000 1:4000
Temp Drift 50 ppm/°C max 50 ppm/°C max
Environmental:
Ambient Temp -22 to +158 °F -22 to +158 °F
(-30 to +70 °C) (-30 to +70 °C)
Humidity 0-90% 0-90%
non-condensing non-condensing
Calibration
Flow sensors are calibrated with 0.876 specific gravity, 140
SUS (32 cSt) hydraulic oil. Standard calibration is done using
3-points and is traceable to NIST, ISO 9001/ANSI Z540-1 & MIL-
STD 45662A.
Nominal
Port Size
Flow Rate Series
Model
with Frequency Out
Model
with 4 - 20 mA Out
Model
with 0 - 5 Vdc Out
SAE 8 0.4 - 7 GPM FSC-375 F2945-ASCM F2945-ASCI F2945-ASCV
SAE 12 1 - 15 GPM FSC-500 F2082-ASCM F2082-ASCI F2082-ASCV
SAE 12 2 - 25 GPM FSC-750 F2083-ASCM F2083-ASCI F2083-ASCV
SAE 16 3 - 60 GPM FSC-1000 F2084-ASCM F2084-ASCI F2084-ASCV
SAE 16 4 - 85 GPM FSC-1005 F2084-ASCM8 F2084-ASCI8 F2084-ASCV8
SAE 20, Code 61 5 - 100 GPM FSB-1250 F2085-ASBM F2085-ASBI F2085-ASBV
SAE 24, Code 61 7 - 200 GPM FSB-1500 F2086-ASBM F2086-ASBI F2086-ASBV
SAE 20, Code 62 5 - 100 GPM FSD-1250 F2085-SCDM F2085-SCDI F2085-SCDV
SAE 24, Code 62 7 - 200 GPM FSD-1500 F2086-SDCM F2086-SCDI F2086-SCDV
SAE 32, Code 62 10 - 350 GPM FSD-2000 F2998-SCDM F2998-SCDI F2998-SCDV
