MODEL NUMBERS
Sanitary Rating
C - COP/SOP (3A Compliant)
Ferrule Size
0 - 0.984 in.
1 - 1.984 in.
2 - 3.047 in.
Meter Size - Flow Range
03 - 0.6 - 3.0 gpm
05 - 0.75 - 7.50 gpm
07 - 2.0 - 15.0 gpm
08 - 3.0 - 30.0 gpm
10 - 5.0 - 50.0 gpm
15 - 15.0 - 180.0 gpm
20 - 40.0 - 400.0 gpm
Bearing Material
A - Ni Bindery
Tungsten
Carbide
Calibration
A - 5 Point (std)
B - 10 Point
C - 20 Point
Meter Body Hub
A - With Hub ¹
B - No Hub
Pickup Option
0 - NEMA 6 - Magnetic
1 - NEMA 6 - Mag
2 - Non NEMA 6 - Magnetic ²
3 - Non NEMA 6 - Mag ²
4 - Non NEMA 6 - Active 4...20 mA ² - (B220-950)
6 - Non NEMA 6 - High Temperature ²
8 - Non NEMA 6 - Active 0...5V DC ² - (B220-951)
9 - None
1 1/2 in. hub for body size 0; 1 in. hub for body sizes 1 and 2.
2 Indoor use only.
B 16 C - - X X X A X X X
Figure 2: Model construction schema
FloClean Flow Rate Chart
Ferrule Size
Flow Ranges K factor
Pulses/Gal
gpm lpm
0 984 in 0 6…3 0 2 3…11 4 20,000
0 984 in 0 75…7 5 2 8…28 4 13,000
0 984 in 2 0…15 0 7 5…56 8 2750
1 984 in 0 75…7 5 2 8…28 4 13,000
1 984 in 2 0…15 0 7 5…56 8 2750
1 984 in 3 0…30 0 11 4…113 5 2686
1 984 in 5 0…50 0 19 0…190 0 870
1 984 in 15 0…180 0 56 8…681 4 330
3 047 in 40 0…400 0 151 4…1514 2 52
Table 1: FloClean flow rates
