8.3 Parameters
Selection of functions Func
Name Value range Description
t.I
0,1...9999 Integrator timeconstant (in minutes)
P.I
-1999...9999 Integrator-Offset
Inputs InP.1
Name Value range Description
InL.1
-1999...9999 Lower input value (Span start)
Oul.1
-1999...9999 Lower output value
InH.1
-1999...9999 Upper input value (Span end)
OuH.1
-1999...9999 Upper output value
t.F1
0...999.9 Filter time [s]
b.F1 0...9999 Filterbandwidth
Limit values Lim1 … Lim 3
Name Value range Description
L.1
-1999...9999 lower limit 1 ( L.1< -1999 = off)
H.1
-1999...9999 upper limit 1 ( H.1< -1999 = off)
HYS.1
0...9999 Hysteresis of limit value 1
dEL.1 0...9999 Alarm 1 delay
L.2 -1999...9999 lower limit 2 ( L.2< -1999 = off)
H.2 -1999...9999 upper limit 2 ( H.2< -1999 = off)
HYS.2 0...9999 Hysteresis of limit value 2
dEL.2 0...9999 Alarm 2 delay
L.3 -1999...9999 lower limit 3 ( L.3< -1999 = off)
H.3 -1999...9999 upper limit 3 ( H.3< -1999 = off)
HYS.3 0...9999 Hysteresis of limit value 3
dEL.3
0...9999 Alarm 3 delay
g
Resetting to factory setting (default)
r Page 36
Parameter-level
46 UNIFLEX SG 45
