5.4 Displays in the operating level
5.4.1 Display line 1
The display value is the value resulting from function.1, function.2, function.3 handling.
It is also called process value (see also section/page 23.)
5.4.2 Display line 2
The value to be displayed continuously in the second LCD line can be selected from different values via the
BlueControl
Ò
engineering tool.
As default, the adjusted engineering unit is displayed.
1
Default settings as setpoint
2
Display of output OUT3 in % (with corre-
sponding scaling)
g
The values in display line 2 can only be displayed, but not changed.
g
Reset to display of the engineering unit is possible by deleting the entry for line 2..
g
With faulty input values, signals dependent on the inputs (e.g. Inp1, Inp2, display value, Out3) also indicate FAIL.
5.4.3 Switch-over with the enter-key
By using the enter-key, different values can be called in display 2.
· 1
Displaying the defined display 2 value (via BlueControl
Ò
).
Standard setting is unit
· 2
Calling up the error list, if messages are supplied.
If there is more than one message with every push of
the enter key the next message is displayed.
!!!
· 3
Calling up the extended operating level, if messages
are supplied. If there is more than one message with
every push of the enter key the next message is displayed.
!!!!
· 4
Returning to the original displayed value.
If for 30 s no key is pushed, the display automatically
returns to the origin.
Operation
19 Displays in the operating level SG 45
1 2 F E
450.3
äüü
Kg
1 2 F E
450.3
55.0
дььь
1 2
1 2 F E
278.3
°C
дььд
1
2
1 2 F E
278.3
FbF.1
дььд
3
ф
ф
ф
1 2 F E
278.3
L.1
дььдь
4
ф
1 2 F E
278.3
°C
дььд
ф
