g
Latched alarms Lim1/2/3 (E-element displayed) can be acknowledged, i.e. reset via digital alarm di1.
For Configuration, see page 41:
ConF / LOGI / Err.r
g
When an alarm is still pending, i.e. unless the error cause was removed ( E display blinks), latched alarms
cannot be acknowledged and reset.
Error-state
Signification
2
Pending error
Change to error status 1after error removal
1
Stored error
Change to error status 0 after acknowledgement in error list 0
0
no error/message
Not visible, except during acknowledgement
g
If sensor errors should not be on the error list any more after error correction without manual reset in the
error list, suppression via BlueControl
Ò
is possible by means of setting ILat.
CONF / othr / ILat
1
blocked
This setting is without effect on limit values Lim.1 … 3 configured for storage.
6.14
Detection and display of sensor and wiring errors
•
Break of the supply-
1)
, measuring or sense lines: "
FAIL
" on the process value display and
"
FbF.1
" in the error list are displayed.
•
Wrong polarity of supply, sense and input signal lines: "
FAIL
" on process value display and
"
POL.1
" in error list are displayed. Detection of wrong polarity of sense takes place during
instrument start-up.
+
Subsequent correction of the sense wiring is detected only after instrument re-start.
(i.e. the instrument must be switched off and on again.)
•
Short circuit of supply and sense lines ==> behaviour as with break of the supply lines: "
FAIL
"
on the process value display and "
FbF.1
" in the error list are shown.
•
Short circuit of measuring lines: measuring signal = 0
•
Overshoot of measurement input: “
FAIL” on process value display and "
FbF.1
" in the error list
are displayed.
Entry of a substitute value (
In.F ) effective in the event of a sensor error is possible.
*
1)
With 4-wire connection, the EX+ line is monitored in addition to the measurement lines.
After a break of the EX minus line, the measured value is not plausible.
