8.3 Parameters
µ The entries marked with this symbol are selectable only with the instrument option fitted.
Function selection Func
Name Value range Description
tEmP 0...9999 Probe temperature for O
2
-measurement
µ
t.I 0,1...9999 Integrator-Zeitkonstante in Minuten µ
P.I -1999...9999 Integrator-Offsetµ
Inputs InP.1 and InP.2
µ
Name Value range Description
InL.1(InL.2) -1999...9999 Input value of the lower scaling point
Oul.1 (OuL.2) -1999...9999 Display value of the lower scaling point
InH.1 (InH.2) -1999...9999 Input value of the upper scaling point
OuH.1 (OuH.2) -1999...9999 Display value of the upper scaling point
T.F1 (t.F2) 0...999,9 Filter time 1 [s]
B.F1 (b.F2) 0...9999 Filter bandwidth
E.tc1(E.tc2) OFF, 0...100 external cold junction compensation, range depends on temperature unit
Counter/frequency input
µ
Name Value range Description
Cnt.d 0,1...9999 Counter divider
Cnt.S 0...9999 Counter start value
Cnt.E 0...9999 Counter end value
Frq.L 0.000...100.0 Lower input value in kHz
Ou.L -1999...9999 Lower output value in phys. units
Frq.H 0.000...100.0 Upper input value in kHz
Ou.H -1999...9999 Upper output value in phys. units
Frq.F
0...9999 Filter time constant in s
Limit values Lim1 … Lim 3
Name Value range Description
L.1 -1999...9999 Lower limit 1 ( L.1< -1999 = off)
H.1 -1999...9999 Upper limit 1 ( H.1< -1999 = off)
HYS.1 0...9999 Hysteresis 1
dEL.1 0...9999 Limit 1 delay
L.2
-1999...9999 Lower limit 2 ( L.2< -1999 = off)
H.2 -1999...9999 Upper limit 2 ( H.2< -1999 = off)
HYS.2 0...9999 Hysteresis 2
dEL.2 0...9999 Limit 2 delay
L.3 -1999...9999 Lower limit 3 ( L.3< -1999 = off)
H.3 -1999...9999 Upper limit 3 ( H.3< -1999 = off)
HYS.3 0...9999 Hysteresis 3
dEL.3 0...9999 Limit 3 delay
g
For resetting the parameters to factory setting (default ),
r section 12.4, 6.17 (page 37)
Parameter setting level
48 Parameters UNIFLEX CI 45
