7.2 Configurations
Dependent on instrument version and configuration settings, display of values which are not required is suppressed.
µ The entries marked with this symbol are selectable only, if the instrument option is fitted.
Function selection Func
Name Value range Description
Fnc.1 Function 1
µ
0 Process value = INP1
2 Difference (INP1 -INP2)
3 Max (INP1, INP2)
4 Min (INP1, INP2)
5 Mean value (INP1, INP2)
6 Switch-over (INP1, INP2)
7 O
2
-Function with constant probe temperature
8 O
2
-Function with measured probe temperature
9 Counter / frequency
10 Process value = INP1 ( TC of INP2)
Fnc.2 Function 2
0 No function
1 Squarer
2 Square root
Fnc.3 Function 3
µ
0 No function
1 Tare
2 Sample & Hold
Inputs InP.1 and InP.2 (
µ)
Name Value range Description
I.Fnc Input function (
µ with 2nd universal input only )
0 No measurement
1 measurement
S.tYP Sensor type
0 Thermocouple type L (-100...900°C), Fe-CuNi DIN
1 Thermocouple type J (-100...1200°C), Fe-CuNi
2 Thermocouple type K (-100...1350°C), NiCr-Ni
3 Thermocouple type N (-100...1300°C), Nicrosil-Nisil
4 Thermocouple type S (0...1760°C), PtRh-Pt10%
5 Thermocouple type R (0...1760°C), PtRh-Pt13%
6 Thermocouple type T (-200...400°C), Cu-CuNi
7 Thermocouple type C (0...2315°C), W5%Re-W26%Re
8 Thermocouple type D (0...2315°C), W3%Re-W25%Re
9 Thermocouple type E (-100...1000°C), NiCr-CuNi
10 Thermocouple type B (0/100...1820°C), PtRh-Pt6%
18 Special thermocouple (linearization necessary)
20 Pt100 (-200.0 ... 100,0 °C) (150°C with reduced lead resistance)
21 Pt100 (-200.0 ... 850,0 °C)
22 Pt1000 (-200.0...850.0 °C)
23 Special 0...4500 Ohm (preset KTY11-6)
Configuration level
UNIFLEX CI 45 Configurations 39
