O.typ, O.act, Lim.1 – West Control Solutions CI 45 User Manual
Page 42: Lim.2, Lim.3, Fai.1, Fai.2, Fai.f, Sb.er, Out.0
Name
Value range
Description
Inf.2
Status message Inf.2 (number of switching cycles) (visible only with BlueControl!)
0
Not active
1
Active
Output Out.3 (analog)
Name
Value range
Description
O.tYP
Type of OUT3
0
Relay / logic (only visible with current/logic/voltage)
1
0 ... 20 mA continuous (only visible with current/logic/voltage)
2
4 ... 20 mA continuous (only visible with current/logic/voltage)
3
0...10 V continuous (only visible with current/logic/voltage)
4
2...10 V continuous (only visible with current/logic/voltage)
5
Transmitter supply (only visible with current/logic/voltage)
6
Frequency µ
O.Act
Direction of operation OUT3 (only visible with O.TYP=0 )
0
Direct / normally open
1
Inverse / normally closed
Lim.1
Signal limit 1 (only visible with O.TYP=0 )
0
Not active
1
Active
Lim.2
Signal limit 2 (only visible with O.TYP=0 )
0
Not active
1
Active
Lim.3
Signal limit 3 (only visible with O.TYP=0 )
0
Not active
1
Active
FAi.1
Signal INP1 fail (only visible with O.TYP=0 )
0
Not active
1
Active
FAi.2
Signal INP2 fail (only visible with O.TYP=0 )
µ
0
Not active
1
Active
FAi.F
Frequency error µ message
0
Not active
1
Active
Sb.Er
System bus error µ message
0
Not active
1
Active
Out.0
-1999
...9999
Lower scaling limit of the analog output (corresponds to 0% (0/4mA bzw. 0/2V, only
visible with O.TYP=1..4)).
Out.1
-1999
...9999
Upper scaling limit of the analog output (corresponds to 100% (20mA bzw. 10V,
only visible with O.TYP=1..4 )).
Out.L
-1999
...9999
Input value for min. output frequency (visible only with O.TYP=6)
µ
FrQ.L
-1999
...9999
Min. output frequency in Hz (visible only with O.TYP=6)
µ
Out.H
-1999
...9999
Input value for max. output frequency (visible only with O.TYP=6)
µ
FrQ.H
0.0...9999
Max. output frequency in Hz (visible only with O.TYP=6)
µ
Configuration level
42
Configurations
UNIFLEX CI 45
