Name
Value range
Description
FrEq
Switching 50/60 Hz (only visible with BlueControl!)
0
Mains frequency 50 Hz
1
Mains frequency 60 Hz
ILat
suppress error latch (only visible with BlueControl!)
0
Enabled
1
Blocked
IExo
Access to extended operation level (only visible with BlueControl!)
0
Enabled
1
Blocked
Pass
OFF...9999
Password (only visible with BlueControl!)
IPar
Access to parameter level (only visible with BlueControl!)
0
Enabled
1
Blocked
ICnf
Access to configuration level (only visible with BlueControl!)
0
Enabled
1
Blocked
ICal
Access to calibration level (only visible with BlueControl!)
0
Enabled
1
Blocked
T.Dis2
Entries for the text in display 2 (max. 5 digits)
(only visible with BlueControl!)
Linearization Lin
Only visible with BlueControl!
Name
Value range
Description
U.LinT
Temperature-unit of linearization table
0
No unit
1
°C
2
°F
3
Kelvin
In.1 … In.32
OFF (from In.3)-1999...9999
Input 1 … Input 32
Ou.1 … Ou.32
-999.0 … 9999
Output 1 … Output 32
g
Value U.LinT defines the unit of input values specified for linearization of temperature values . Value entry
in Celsius despite display of the measured value in Fahrenheit is possible.
w
Specify the input signals mV, V, mA, % or Ohm dependent on input type.
w
For special thermocouples (S.tYP = 18), specify the input values in
mV and the output values in the temperature
unit adjusted in U.LinT.
w
For special resistance thermometer (KTY 11-6) (S.tYP = 23), specify the input values in Ohm and the output value
in the temperature unit adjusted in U.LinT .
g
For resetting the instrument configuration to factory setting (default ),
r section 12.4, 6.17 (page 37)
