C.6
TRICOR Systems Inc.
Table C.2 4
5, 10 mA or 25 mA Resistance Option using Resistance
Fixture PN 921-811-09
Resistance Switch Position Displayed Value (
5)
Tolerance
1 (0
5)
0.000 ±.010
2 (1
5)
1.000 ±.010
3 (2
5)
2.000 ±.010
4 (3
5)
3.000 ±.010
5 (3.8
5)
3.800 ±.010
6 (.025
5)
0.025 ±.010
7 (.050
5)
0.050 ±.010
8 (.075
5)
0.075 ±.010
Table C.3 16 k
5, .25 mA Resistance Option using Resistance Fixture
PN 921-811-01
Resistance Switch Position Displayed Value* Tolerance
0 (0 k
5)
0.000 ± 0.010
1 (4 k
5)
1.000 ± 0.010
2 (8 k
5)
2.000 ± 0.010
3 (12 k
5)
3.000 ± 0.010
4 (16 k
5)
4.000 ± 0.010
* Resistance = Displayed Value x 4000 (
5)
Table C.4 1 k
5, 1 mA Resistance Option using Resistance Fixture
PN 921-811-07
Resistance Switch Position Displayed Value* Tolerance
0 (0
5)
0.000 ± 0.010
1 (250
5)
1.000 ± 0.010
2 (500
5)
2.000 ± 0.010
3 (750
5)
3.000 ± 0.010
4 (1000
5)
4.000 ± 0.010
* Resistance = Displayed Value x 250 (
5)
