SHIMPO 921A User Manual

Page 3

TRICOR Systems Inc.

1.2

* Other ranges available.

† Related to free position.

TABLE 1-1

MODEL 921A DISPLACEMENT - FORCE TEST STATION

SPECIFICATIONS

Power Requirements

115/220 V ac, 50/60 Hz, 230 VA

Test Cycle Time

6 to 10 seconds typ

Resistance Test Current

10 mA standard*

Resistance Measurement

One (Optional)

Channels

Displacement*

Range:

6.25 to 62.51 mm (0.246 to 2.461 inches)

standard*

Resolution:

0.00254 mm (0.0001 inch)

programmable

Abs Accuracy†:

±0.00762 mm (±0.0003 inch) max
±0.00254 mm (±0.0001 inch) typ
±0.00762 mm (±0.0003 inch) max
±0.00254 mm (±0.0001 inch) typ

Force*

Range:

0 to 3.6 kg (0 to 8 lb)

standard*

Resolution:

1 g (0.035 oz)

Abs Accuracy:

±0.25% of fsc max, ±0.2% of fsc typ

Repeatability:

±0.1% of fsc max, ±0.05% of fsc typ

Resistance* (Optional)

Range:

0 to 4

standard*

Resolution:

1 m

Abs Accuracy:

±0.25% of fsc max, ±0.1% of fsc typ

Repeatability:

±0.1% of fsc max, ±0.05% of fsc typ
