SHIMPO 921A User Manual
Page 12
TRICOR Systems Inc.
2.2
Figure 2.1 921A DF Test Station Interconnect
PRECISION DRIVE
MECHANISM
GENERIC NEST
PN 921-140-
(OR USER NEST)
MODEL 921A
DF TEST STATION
J1
SERIAL COM
CHANNEL
PC
110 - 120 VAC OR
220 - 240 VAC
RESISTANCE CABLE
WARNING
Set up unit for facility power (115 or 220 Vac) prior
to connecting to facility power (see paragraph 2.1).
15-PIN MALE
25-PIN MALE
SERIAL CABLE
25-PIN FEMALE
(9-PIN OPTIONAL)
J2
15-PIN FEMALE
