Operation
25 38857
Indicator Lights
WASH
WASH is lit at the beginning of a Wash cycle and will
remain lit until the Wash cycle is complete.
RINSE
RINSE
is lit at the beginning of the Rinse or Extra
Rinse cycle and will remain lit until the cycle is
complete.
SOAK
SOAK is lit at the beginning of all Pause cycles.
During a Wash Pause cycle, the display will light
“WASH SOAK” and during a Rinse or Extra Rinse
Pause cycle, the display will light “RINSE SOAK.”
SPIN
SPIN is lit for all Spin cycles. During a Wash Spin
cycle, the display will light “WASH SPIN” and during
an Extra Rinse Spin Cycle, the display will light
“RINSE SPIN”. At the beginning of Final Spin, the
display will light “SPIN.”
PRICE
PRICE is lit to indicate that value displayed is the
vend price remaining to be satisfied. Once the vend
price is satisfied, the word “PRICE” will go off.
TIME REMAINING
TIME REMAINING is lit to indicate that the number
displayed by two digits and the colon is the time
remaining in the current cycle. It will light at the start
of the cycle and remain lit until the cycle is completed.
INSERT COINS
INSERT COINS
is lit to prompt the user for coins to
satisfy the vend price. When INSERT COINS is lit, the
three digits and decimal point show the vend price
remaining to be satisfied.
UNBALANCE
UNBALANCE is lit and will flash when the washer is
in a Spin mode and the lid is opened.
IMPORTANT: If washer fails to operate properly
after installation, make sure electrical service and
water supply faucets are turned on. Are all the
controls properly set? Have a qualified service
person refer to the wiring diagram (located inside
of washer control hood) and check for broken,
loose or incorrect wiring.
Should washer stop, but IN USE, RINSE or SPIN light
remain on, the motor overload protector may have
cycled. Refer to page 33.
The washer will stop (pause) shortly before the first
spin and final spin.
To reduce the risk of bodily injury, do not
remove laundry from washer until all
lights are out, and all moving parts have
stopped.
W092
WARNING
