Field Deployment
Program the Instrument
In order to set up a log or download data, you must connect the instrument to a
computer running Win-Situ 5 Software, or a RuggedReader Handheld PC running Win-
Situ Mobile. See page 51.
Position the Instrument
Place the instrument at the desired depth. Position the instrument below the lowest
anticipated water level, but not so low that the pressure sensor range might be
exceeded at the highest anticipated water level. Refer to the tables below to determine
usable depth.
A BaroTROLL Instrument can be deployed with a non-vented
instrument to compensate level data for atmospheric pressure
data. Make sure the clocks on both instruments are synchronized,
and install the BaroTROLL in a location that will never be
submerged in water.
See page 40.
Range
Effective Range
Usable Depth
PSIA
PSIA
kPA
Meters
Feet
30
15.5
106.9
10.9
35.8
100
85.5
589.5
60.1
197.3
300
285.5
1968
200.7
658.7
500
485.5
3347
341.3
1120
1000
985.5
6795
692.9
2273
* At sea level (14.5 PSI atmospheric pressure)
Non-Vented Level TROLL Instrument
