BaroTROLL Instrument
The titanium BaroTROLL measures and logs barometric pressure and temperature.
Use the BaroTROLL in conjunction with non-vented In-Situ Instruments.
Win-Situ BaroMerge Software simplifies post-correction of water level data by
automatically subtracting barometric readings from data collected by a non-vented
instrument to compensate for changes in pressure due to barometric fluctuations.
General BaroTROLL
Temperature ranges 1
Operational: -20-80° C (-4-176° F)
Storage: -40-80° C (-40-176° F)
Calibrated: -5-50° C (23-122° F)
Diameter 1.83 cm (0.72 in.)
Length 21.6 cm (8.5 in.)
Weight 197 g (0.43 lb)
Materials Titanium body; Delrin nose cone
Output options Modbus/RS485, SDI-12, 4-20 mA
Battery type & life 2 3.6V lithium; 10 years or 2M readings
External power 8-36 VDC
Memory
Data records
3
Data logs
1.0 MB
65,000
2
Log types Linear
Fastest logging rate & Modbus rate 1 per minute
Fastest SDI-12 & 4-20 mA output rate 1 per second
Real-time clock Accurate to 1 second/24-hr period
Sensor Type/Material Piezoresistive; titanium
Range 0 to 16.5 psi; 0 to 1.14 bar
Burst pressure Vaccum/over-pressure above 16.5 psi damages sensor
Accuracy @ 15° C 4 ±0.1% FS
Accuracy (FS) 5 ±0.2% FS
Resolution ±0.005% FS or better
Units of measure Pressure: psi, kPa, bar, mbar, mmHg, inHg, cmH
2
O, inH
2
O
Temperature Sensor
Accuracy & resolution ±0.1° C; 0.01° C or better
Units of measure Celsius or Fahrenheit
Warranty
2 years
Up to 5-year extended warranties are available for all instruments—call for details
Footnotes See See page 9.
