SIRIUS 87
EN - 68
- Global earth resistance (R
a15mA
)
Measuring range ( ) Resolution ( ) Accuracy
1
 1999
1
(5% rdg + 3 dgt)
Test current 15mA
Phase to earth test voltage 100
 265V 50Hz 0,5Hz
- Earth resistance measurement with voltamperometric method
Measuring range ( ) Resolution ( ) Accuracy
0,01
 19,99
0,01
(5% rdg + 3 dgt)
20,0
 199,9
0,1
200
 1999
1
Test current <10mA 77,5Hz
Open load test voltage <20V RMS
- Earth resistivity
 measurement
Measuring range ( ) Resolution ( m) Accuracy
0.06
 19,99 m 0,01 m
(5% rdg + 3 dgt)
20.0
 199.9 m 0.1 m
200
 1999 m 1 m
2,00
 19,99 km 0.01
k
m
20.0
 125,5 km (*)
0.1 k
m
(*) with D = 10m
Test current
<10mA 77,5Hz
Open load test voltage <20V RMS
9.1.1. Reference standards
Safety:
IEC/EN61010-1 + A2(1997)
Product norms: IEC61557-1, -2, -3, -4, -5, -6
Insulation: double insulation
Pollution level: 2
Max height of use: 2000m (6562ft)
Overvoltage category: CAT III 460V
 B1-B2-B3-B4 / 265V to ground
9.1.2. General specifications
Mechanical features
Dimensions (L x W X H):
222 x 165 x 105mm (9 x 6 x 4in)
Weight (batteries included): 1.2kg (42 ounces)
Power supply
Battery type:
6x1.5V batteries type LR6 AA AM3 MN 1500
Low battery indication: symbol is displayed
Battery life: About 40 hours in stand-by or
500 Low
 tests or
250 R
ISO
tests 500V/500k
 or
1000 Loop, RCD o phase sequence tests
300 Earth or
 tests.
Display:
LCD custom 65mmx65mm
Memory: 350 tests
Serial interface:
optoisolated RS232 to download stored data to a PC.
