I-V400 - SOLAR I-V
EN - 69
10.4. GENERAL CHARACTERISTICS
Display and memory
Type of display:
LCD custom, 128x128 pxl, backlighted
Memory capacity:
256kbytes
Saved data:
99 yield tests (SOLAR I-V only
); 249 I-V, 999IVCK
PC interface:
optical / USB
PV Yield Test (only SOLAR I-V)
Integration period (IP):
5,10,30,60,120,300,600,900,1800,3600s
Memory authonomy SOLAR-02:
approx 1.5 hours (@ PI = 5s)
approx 8 days (@ PI = 600s)
Max distance RF connection:
1m (3 ft)
Memory of SOLAR-02 - MPP300:
approx. 1.5 hours (@ PI = 5s)
approx. 8 days (@ PI = 600s)
Power supply
Battery type:
6 x1.5 V alkaline type AA L&06
Low battery indication:
symbol “
“ is displayed
Battery life:
approx 120 hours (PV Yield test)
>249 I-V curve test, 999 IVCK test
Auto power off:
after 5 minutes of idleness
Mechanical data
Size:
235(L)x165(W)x75(H)mm ; 9(L) x 6(W) x 3(H) in
Weight (batteries included):
1.2kg (42 ounces)
10.5. ENVIRONMENT CONDITIONS
Reference temperature:
23° ± 5°C (73°F ± 41°F)
Working temperature:
0 ÷ 40°C (32°F ÷ 104°F)
Relative humidity allowed:
<80%RH
Storage temperature:
-10 ÷ 60°C (14°F ÷ 140°F)
Storage humidity:
<80%RH
Max height of use:
2000m (6562 ft) (*)
CAUTION
(*) Information about the use of meter at altitude from 2000 to 5000m
As for voltage inputs P1, P2, C1, C2 the instrument is to be considered downgraded to
overvoltage category CAT I 1000V DC and CAT II 300V to ground, max 1000V among
inputs. Markings and symbols indicated on the instrument are to be considered valid when
using it at altitude lower than 2000m
This instrument complies with the prescriptions of the European directive on low
voltage 2006/95/CE (LVD) and EMC 2004/108/CE
10.6. ACCESSORIES
See enclosed Packing List
