I-V400 - SOLAR I-V
EN - 16
5.2.2.2. PV plant parameters
1. Press MENU key, position the cursor onto EFF by using
the arrow keys (
,) and confirm with ENTER. The
display shows the screen here to the side, which contains
the global parameters of the system.
15/05/10 15:34:26
P R p - - -
I r r - - - W / m 2
P n o m 1 5 0 . 0 k W
T c - - - ° C
T e - - - ° C
P d c - - - k W
P a c - - - k W
n d c - - -
n a c - - -

G O – s t a r t r e c .
Select M P P
2. Press the ENTER key. The instrument shows the
following options: MPP300 status, Set PV plant. and Set
Instrum.
3. Use the arrow keys (
,) to select “Set PV plant” and
confirm with ENTER. The instrument shows the following
screen:
15/05/10 15:34:26
P R p - - -
I r r - - - W / m 2
P n o m 0 . 0 0 0 k W
T c - - - ° C
T e - - - ° C
P d c 0 . 0 k W
V d c 0 . 0 0 0 V
I d c 0 . 0 A
n d c - - -
M P P 3 0 0 s t a t u s
Set PV plant
S e t i n s t r u m .
Select M P P
4. By using the arrow keys (
 , ) it is possible to set:
 Pmax  maximum rated power of PV installation
expressed in kW
 Range  coefficient of power variation with
temperature, characteristic parameter of PV modules
(typically in range: -0.3
 -0.5%/C)
 Noct  rated operating temperature of the cell,
characteristic parameter of PV modules (typically in
range: 42
 48°C)
 Te, Tc  setting of default values of environmental
and PV module temperatures. These values are taken
into consideration by the instrument only when probe
is not connected to unit SOLAR-02
 Corr. Type  Setting of the compensation
relationship on the calculation of Pdc power and the
maximization of DC performance (see § 5.2.3)
15/05/10 15:34:26
P m a x :  3 . 5 0 0  k W
G a m m a : 0 . 4 5 % / ° C
N o c t : 4 5 ° C
T e : 4 0 ° C
T c : 4 5 ° C
C o r r . T y p e . : T . E n v
S A V E t o s t o r e d a t a
M P P
