5.3.2. How to modify a PV module
1. Select the PV module to be modified from the internal
database by means of arrow keys (
,).
2. Press the ENTER key and select the “Modify” command
by means the arrow key (
).
3. Confirm the selection with ENTER.
15/05/10 15:34:26
T y p e :  S U N P O W E R 2 1 0 

P m a x = 2 1 0 W
V o c = 4 7 . 7 0 V
V m p p = 4 0 . 0 0 V
I s c = 5 . 7 5 A
N e w
M o d i f y
D e l e t e
D e l . A l l
S e l e c t D B
4. By using the internal virtual keyboard it is possible to
define a different name of the module by means of arrow
keys (
,,,). Press ENTER to digit any character of
the desired name.
5. Press the SAVE key to save the new name of the module
as defined or to access the new setting of parameters.
15/05/10 15:34:26
T y p e :  S U N P O W E R 2 1 0 

P m a x = 1 8 5 W
V o c = 4 4 . 5 V
K E Y B O A R D
S U N P O W E R 2 1 0
A B C D E F G H I J K L M N O P
Q R S T U V W X Y Z - +
0 1 2 3
4 5 6 7 8 9 S P A C E D E L
SAVE/ESC
6. Select the desired parameters to be modified by means of
arrow keys (
,) and change values by means of arrow
keys (
,). Press and hold the (,) for a quick setting
of values. If the value of any parameter is unknown, press
and hold the HELP key for some seconds to set the
default values.
7. Confirm with SAVE and the “Saved data” message is
displayed for a while. Press ESC/MENU key to exit
without saving and to go back to the previous screen.
15/05/10 15:34:26
T y p e : S U N P O W E R 2 1 0

P m a x =  2 1 0  W
V o c = 4 7 . 7 0 V
V m p p = 4 0 . 0 0 V
I s c = 5 . 7 5 A
I m p p = 5 . 2 5 A
T o l l - = 5 %

D B
5.3.3. How to delete a PV module
1. Select the PV module to be deleted from the internal
database by means of arrow keys (
,).
2. Press the ENTER key and select “Delete” command by
means of arrow key (
) to delete the selected module.
3. Press the ENTER key and select “Del. All” command by
means of arrow key (
) to delete all modules in the
database (except for “DEFAULT”).
4. Confirm the selection with ENTER or press ESC/MENU to
exit
15/05/10 15:34:26
T y p e :  S U N P O W E R 2 1 0 

P m a x = 2 1 0 W
V o c = 4 7 . 7 0 V
V m p p = 4 0 . 0 0 V
I s c = 5 . 7 5 A
N e w
M o d i f y
D e l e t e
D e l . A l l
S e l e c t D B
CAUTION
It is not possible to modify or delete the “DEFAULT” PV module which is the
standard reference factory module.
