CONNECTION & CONFIGURATION

11

C

ONNECTION &

C

ONFIGURATION

After installing the software and driver to the PC, the remote control

connection needs to be established on the GDM 825XA DMM.
NOTE: If you are using DMM-Viewer in software demonstration mode (no
hardware) skip the Connection and Configuration procedure and see page 18.

1. Installing the
software and
driver

Follow the procedures on page7.

The following procedure describes a USB
connection configuration and procedure. The
GDM8200A also supports RS232. If using RS232,
follow the same procedure to disable USB, if it is
not already.

2. Configure the
GDM series

1. Press the Shift key, the 2

ND

(Menu) key, then the Right

key twice. The I/O

configuration menu appears.

2. Press the Down key until the

USB selection display

appears.
