APPENDIX

39

Power Supply Specifications

Model-specific specifications

Cable Lengths

Sensor cable Approx. 1.5 m (59.0"),
Power supply cable Approx. 1 m (39.4")


GCP-425P

GCP-206P

Number of power
supply connectors

4 2

Rated output
current

±2.5 A (sum total of all
channels)

600 mA (sum total of all

channels and all output

voltages)

Ripple voltage

50 mVp-p or less

3 mVp-p or less (at rated

output current)

Load influence

Within output voltage limits

indicated above for current

output in the range 0 to ±2.5

A

Within output voltage limits

indicated above for current

output in the range 0 to 600

mA

Maximum rated
power

170 VA

20 VA

Dimensions

Approx.

80W × 119H × 200D mm

3.15"W × 4.69"H × 7.87"D

Approx.

73W x 110H x 186D mm

2.87"W x 4.33"H x 7.32"D

Weight

Approx.1.2 kg (42.3 oz.)

Approx. 1.1 kg( 38.8 oz)

Accessories

Instruction Manual, Power
cord

Power cord, Instruction

manual, Spare fuse

F1.0 AL/250 V, 20 mm x 5

mm dia. (for 100 V and 120 V

models) or F0.5 AL/250 V, 20

mm x 5 mm dia. (for 220 V

and 240 V models

Rated supply
voltage

100 to 240V AC (50/60Hz)
(Voltage fluctuations of ±10%
from the rated supply voltage
are taken into account.)

100 V AC (120, 220, and 240

V require specification)

(Voltage fluctuation of 10%

from the rated supply voltage

are taken into account.)

Power supply
voltage influence

Within output voltage limits
indicated above for the rated
power supply voltage,
10%
