GW Instek GDS-3000 Series GCP-530/1030 current probe User Manual User Manual
Page 16
GCP Series User Manual
16
DANGER
To avoid electric shock, do not touch the portion
beyond the protective barrier during use.
NOTE
•
The output of this device is terminated
internally. Use a high-impedance input to the
measuring instrument. With an input
impedance of 50Ω, accurate measurement is not
possible.
•
If using BNC-banana plug adapters or similar to
connect to input terminals other than BNC
connectors, make sure the polarity is correct.
•
Turn the collar until it clicks, and check that it is
locked securely.
