Ppendix, Fuse replacement (for gcp-206p only) – GW Instek GDS-3000 Series GCP-530/1030 current probe User Manual User Manual
Page 32
GCP Series User Manual
32
A
PPENDIX
The power supply fuse for the GCP-425P, and the
power supply voltage selector, are housed in the
power input socket on the rear panel.
Fuse Replacement (for GCP-206P only)
Procedure
1. Turn the power switch off, and then disconnect
the power cord.
2. Using a flat screwdriver, pry the catch which
holds the fuse holder into the power input
socket as shown in the figure, and then remove
the fuse holder.
