Getting to Know Your Printer
The illustrations below describe parts and features of the FM 4600 PLUS Series
printer.
Front Panel
Control Panel
LED‟s and
Switches
LCD Message
Display
Top Access
Door
Front Access
Door
The front panel includes:

3 LED indicators (READY, MEDIA and RIBBON)

3 buttons (FEED, PAUSE and CANCEL)

LCD display

Top Access Door

Front Access Door
Printer Models:
 TIA-200V (FM 4602 PLUS / 203dpi)
 TIA-230E (FM 4602 PLUS / Int. Ethernet 203dpi)
 TIA-320 (FM 4603 PLUS / 300dpi)
 TIA-320E (FM 4603 PLUS / Int. Ethernet 300dpi)
