46
Light /Missing Print
Print quality can be adjusted when light or missing print is primarily observed on
the right or left side of the media.
If the print discrepancy is as shown in Fig. 1, turn the Fine Adjustment Knob
clockwise one setting (adjust counter clockwise for Fig. 2 correction), then try
printing again to justify the print quality improvement. Repeat the same process
until the print quality is well balanced on both sides of the label.
Light/Missing Print
Figure 1 Figure 2
Fine Adjustment
Knob
6
4
4
2
2
0
6
Figure #1, Light Print Correction
Adjust Clockwise
Figure #2, Light Print Correction
Adjust Counter Clockwise
