Model 1000 CO2

Model 1000 CO2 Instruction Manual

Rev. 2.2

Page 21 of 28

Bit 7

1-Alarm 2 Relay is energized

0-Alarm 2 Relay is not energized

Bit 6

1-Alarm 1 is ascending

0-Alarm 1 is descending

Bit 5

1-Alarm 1 is normally energized

0-Alarm 1 is normally de-energized

Bit 4

1-Alarm 1 is latching

0-Alarm 1 is non-latching

Bit 3

1-Alarm 1 Relay is energized

0-Alarm 1 Relay is not energized

Bit 2

1-Fault is normally energized

0-Fault is normally de-energized

Bit 1

1-Fault is latching

0-Fault is non-latching

Bit 0

1-Fault Relay is energized

0-Fault Relay is not energized


The following is a typical Master Query for device # 8:
Field Name

HEX DEC RTU

Slave Address

08

8

0000 1000

Function

03

3

0000 0011

Start Address Hi

00

0

0000 0000

Start Address Lo

00

0

0000 0000

No. of Registers Hi

00

0

0000 0000

No. of Registers Lo

06

6

0000 0110

CRC

##

#

#### ####

CRC

##

#

####

####


The following is a typical Slave Response from device # 8:
Field Name

HEX DEC RTU

Slave Address

08

8

0000 1000

Function

03

3

0000 0011

Byte Count

0C

12

0000 1100

Reg40000 Data Hi

02

2

0000 0010

Reg40000 Data Lo

64

100

0110 0100

Reg40001 Data Hi

00

0

0000 0000

Reg40001 Data Lo

64

100

0110 0100

Reg40002 Data Hi

00

0

0000 0000

Reg40002 Data Lo

07

7

0000 0111

Reg40003 Data Hi

00

0

0000 0000

Reg40003 Data Lo

0A

10

0000 1010

Reg40004 Data Hi

00

0

0000 0000

Reg40004 Data Lo

14

20

0001 0100

Reg40005 Data Hi

05

5

0000 0101

Reg40005 Data Lo

50

80

0101 0000

CRC

##

#

####

####

CRC

##

#

####

####


Additional Notes:
The calibration LED will light when the transmitter is sending a response to a Master Query. Communications
are 9600 baud, 8 data bits, 1 stop bit, No parity, and half duplex 485.

11.0 Sensor Replacement


Should the optical gas sensor element (part number 370-365878-111(IR-640) or 370-287724-332 (IR-642))
require replacement, use the following procedure:
1 - (A) If the sensor is mounted in a classified area, system power to the transmitter must first be removed
before proceeding further.

(B) If the sensor is in an unclassified area, remove front enclosure cover and unplug transmitter module.
