Strobe
Antenna
Charger
Connector
(Optional)
External Alarm
Connector
Sentinel Relay PCA
and 4-20mA PCA
Power LED
RXT-320
Xcvr
Battery Pack
Power
Switch
Sensor Ports
Sonalert
NOTE:
Unit shown has the max options:
Power Input Port
4 sensor ports
Alarm Output connector
Strobe and Sonalert Horn
All dimensions are in inches
Cover removed for clarity
