Sentinel CX
Sentinel CX Sensor Station IM Rev. 1.4 Page 19 of 26
5. Maintenance and Service Personnel Activities
NOTE
Only service or maintenance related activities as described below in Sections 5.1- 5.4 are
allowed to be performed by the on-site un-certified service personnel. Any other required
service or maintenance related activity shall only be performed by a Factory-Certified
Detcon technician.
CAUTION
Any maintenance or servicing performed outside the allowable scope of this section
may impair the safe operation of this device.
The following is a list of items that are supplied standard with the CX Sensor Station. They can also be
purchased for service or maintenance needs. These components are only to be supplied by Detcon as part of
this product configuration. No substitutions are allowed.
Rechargeable Battery Pack (Detcon PN 360-3S6PFP-290)
Condensation Prevention Packet (Detcon PN 960-798434-000)
Battery Charging Accessory (Detcon PN 976-0003BC-00T or PN 976-0003BC-220)
5.1 Replacement of Condensation Prevention Packet
On an annual or bi-annual basis, the Condensation Prevention packet should be exchanged with a new
packet. Remove the CX Sensor Station to a non-hazardous area and turn power OFF. Open hinged door
and locate packet. Remove packet and replace with a new packet in the same physical position. Close
hinged door and turn power ON.
5.2 Replacement of Lithium Ion Battery Pack
Warning
Explosion Hazard. Do not remove or replace the Lithium Ion Battery Pack unless
power has been disconnected or unless the area is known to be free of ignitable
concentrations.
If there are any warnings or fault indicators that suggest there is a problem with the lithium ion battery pack
(ie. not charging when expected), it should be removed and replaced. Relocate the CX Sensor Station to a
non-hazardous area and remove power from the CX Sensor Station by turning the power switch to OFF.
Open the hinged door to gain access to interior.
Locate the four screws that attach the metal bracket that
secures the battery pack. Undo the four screws and set them aside carefully. Lift metal bracket and expose
battery pack. Disconnect the two wire male/female connector to free the pack. Replace the old pack with a
new pack and reverse the directions given above, making sure the wire connections are made correctly.
5.3 Proper Cleaning Procedure
If the unit requires cleaning, take a clean water-damped wet cloth and wipe off the exterior surfaces of the
unit as required. Allow for air dry. It is not necessary to relocate the unit to a non-hazardous area to
perform cleaning.
