RXT-320 Wireless Modbus ™
RXT-320 Wireless IM Rev. 2.1 Page 24 of 27
4.2.10 Register – Timestamp
Three registers are utilized to maintain a timestamp that increments on the microcontroller after power up.
These are all set to 0 upon power up or a microcontroller reset. The first two registers 8208 and 8209 are
internally combined into a single 32 bit register and incremented each second.
The last register 8210
maintains the millisecond count and will count from 0 to 999 and start over again.
5.0 Troubleshooting Guide
Power Problems
Probable Causes: Depleted battery/Low Charge, battery not seated properly.
Recharge or replace battery.
Reseat battery.
Transceiver not Responding
Probable Causes: Incorrect jumper settings on term board, incorrect wiring, connectors not seated properly.
Verify jumper settings are properly configured.
Verify transceiver wiring matches color coding on term board.
Verify connectors are seated correctly and not offset. Reseat connector is necessary.
Modbus™ Communication Problems
Probable Causes: Incorrect Modbus™ address, incorrect rotary switch settings, incorrect wiring.
Verify Modbus™ address corresponds to the appropriate function desired (Master, Slave, Transparent Mode,
Alarm Station).
Verify there are no duplicate Modbus™ addresses on the network.
Verify Modbus™ address has been configured correctly on term board rotary switches.
Verify correct polarity on Modbus™ wiring.
Condensation Problems
Probable Causes: Loose cover on T-Outlet box, loose cover on transceiver housing, loose NPT connections to
condulet/j-box, expired condensation prevention packet.
Verify cover is tight on T-Outlet box and transceiver housing.
Verify all NPT connections are secure and tight.
Replace condensation prevention packet.
6.0 Warranty
Detcon, Inc., as the manufacturer, warrants under intended normal use each new Model RXT-320 wireless
transceiver to be free from defects in material and workmanship for a period of one year from the date of
shipment to the original purchaser. Should the transceiver fail to perform in accordance with published
specifications within the warranty period, return to Detcon, Inc. for necessary repairs or replacement. All
warranties and service policies are FOB the Detcon facility located in The Woodlands, Texas.
