Monitoring port pin assignments: figure 9, Continued, Specifications – APC SMARTSLOT DP300E User Manual
Page 34: Continued on next page
28
The following figure shows the Monitoring port pin
assignments.
Figure 9:Monitoring port pin assignments
Continued on next page
9
1
2
4
6
5
3
UPS Shut Down RS-232 Input or
Advanced Mode RS-232 Data Rx In
Line Fail RS-232 Output or
Advanced Mode RS-232 Data Tx Out
Chassis
Common
Normally Closed
Line Fail Signal
Normally Open
Low Battery Signal
Normally Open
Line Fail Signal
HI
4.5 s
6 7 8 9
1 2 3 4 5
8
Unregulated
+24 VDC Output
