Connecting the chassis to the ups: figure 7, Serial port of the silcon ups. see “con, Continued – APC SMARTSLOT DP300E User Manual
Page 17: Configuring via the monitoring port
11
Configuring via the Monitoring Port
This figure shows the connection panel of a Silcon
DP310E
UPS
. Other models vary.
Figure 7:Connecting the chassis to the UPS
Continued on next page
24 VDC Power Supply
DB-25 Serial Ports
