IGA 6/23 Advanced Manual Data format UPP Ò · 38
Description Command Parameters
Response time t
90
AAezX X=0 to 9
0=min 1=1 ms 2=3 ms 3=5 ms
4=10 ms 5=50 ms 6=250 ms
7=1 s 8=3 s 9=10 s
Dynamic exposure
time AAdmX X=0 to 9
0 = off, 1 = min, 9 = max
Temp display °C or °F AAfhX Output: X=0 Display in °C
X=1 Display in °F
Device address AAgaXX XX=(00 to 97)
00 to 97=regular device addresses
99=global address with response
Internal temperature
(read) AAgt
AAtm
Answer: DDD 3 decimal digits (000 to 098 °C or
032 to 210 °F)
gt=current temp.
tm=maximum temp. (memory)
Ambient temperature
compensation
AAutXXXX XXXX = value of ambient temperature, 4-digit, hex
XXXX e.g. FFEC corresponds to -20 degrees
-99dez = FF9Dhex means: automatic, no manual
compensation
Laser AAlaX
AAla X=0 off X=1 on
Answer: 1-digit: “0” or “1”
Wait time AAtwXX XX = 00 … 99
(decimal, in bit time of the current baud rate)
Software simulation
of external clearance AAlx Clears maximum storage
Clear peak memory
t
clear
AAlzX X=0 to 9
0=OFF
1=10 ms 2=50 ms 3=250 ms
4=1 s 5=5 s 6=25 s
7=EXTERN 8=AUTO 9=HOLD
Basic range (read) AAmb Answer: XXXXYYYY
2x4 hex-digit for lower and upper range limit (°C or °F)
Sub range (read) AAme Answer: XXXXYYYY
2x4 hex-digit for lower and upper range limit (°C or °F)
Sub range (set)
1. AAm1XXXXYYYY
XXXXYYYY=2x4 hex-digit for lower and upper sub range
limit (°C or °F)
2. AAm2 AAm2 confirms the change (auto reset)
Measuring value AAms Answer: QQQQQ (88880=Overflow)
5 decimal digit (in °C or °F, last digit is 1/10 °C or °F)
Device type AAna Output: “IGA 6/23 Advanced”
(16 ASCII-characters)
