IGA 6/23 Advanced Manual Introduction · 10
Optics
Sighting:
Built-in laser aiming light (max. power level < 1 mW, λ = 630 to 680 nm,
CDRH class II) or through-lens sighting
Optics: Manually focusable from rear cover measuring distance
a = 210 to 5000 mm
Distance Ratio: MB 10: approx. 50 : 1
MB 13: approx. 100 : 1
MB 18: approx. 350 : 1
Environment
Protection Class:
IP 65 IEC 60529 (value in mated condition)
Operating Position: Any
Ambient Temperature:
Note: During operation the
instruments will warm up and might
reach an intrinsic temperature of up
to 58 °C
0 to 70 °C at housing
Storage Temperature: -20 to 80 °C
Relative Humidity: Non condensating conditions
Weight: 0.6 kg
Housing: Stainless steel
CE-Label: According to EU directives about electromagnetic immunity
Interface
Connection:
12-pin connector
Display (in rear cover): LED, 4 digit matrix, 5 mm high temperature signal or measuring
distance
Parameters: Adjustable via interface:
emissivity, sub range, ambient temperature compensation, wait time t
w
,
settings for maximum value storage, address, baud rate, transmittance,
response time t
90
, 0 to 20 mA or 4 to 20 mA analog output range, °C/°F
Readable via interface: measured value, internal temperature of the
unit, measuring distance
Communication
Analog Output:
Adjustable 0 to 20 mA or 4 to 20 mA, linear (via digital interface)
Digital Interface: RS485 addressable (half-duplex)
Baud rate: 1200 Bd to 115.2 kBd (on request RS232, not addressable)
Maximum Value Storage: Built-in single or double storage. Clearing with adjusted time t
clear
(off;
10 ms; 50 ms; 250 ms; 1 s; 5 s; 25 s), via interface, automatically with the
next measuring object, hold-function
Electrical
Power Supply:
24 V DC ± 25%, ripple must be less than 50 mV
Power Consumption: Max. 3 W (incl. laser)
Load (analog output): 0 to 500 Ohm
Isolation: Power supply, analog output, and digital interface are galvanically
isolated from each other
