Page 8: Warning
Part No. 4801-0172 Rev 10/05
PowerTrak Jr.
Page 8 of 18
7.
Mounting Machine On Structure
Important!
Maximum Load Is 700 Lbs. (317.5 kilograms). Do Not Overload Machine!
Select mounting configuration which best fits your needs. Refer to cabling setups in
Section 8. Use a separate machine on each side of a structure.
Warning!
NEVER Connect This Machine To Cables On More Than One Side Of Structure!
Damage Or Injury May Result!
CORRECT INCORRECT
Outside Center
Mount
Inside Center
Mount
Outside Sidewall
Mount
Outside
Endwall
Mount
Inside
Endwall
Mount
