6. Installation
6.1 Tools
Required
7/16 in. (11.1 mm) Socket
9/16 in. (14.3 mm) Socket
Cable Cutters
Small screwdriver
3/8 in. (9.5 mm)
Ratchet & extensions
3/16 in. (4.7 mm)
T-20 Driver
1/4 in. (6.3 mm)
Nut Driver
Wire strippers
Flat Head Screwdriver
Phillips head screwdriver
6.2 Instructions
6.2.1 Unpacking
machine
1. Unpack the PowerTrak Jr. and check the machine for any physical defects.
2. Select a mounting configuration. The PowerTrak Jr. will operate in any position,
however it is important to mount the PowerTrak Jr. so that the cabling does not wear
during operation.
Warning!
Do Not Connect Electrical Power Until Machine Is Securely Mounted And
Installation Is Complete.
Warning!
The 3/8" lag bolt is used for hanging the machine during installation.
Do not attempt to operate the machine until machine is securely mounted.
H IR ED -H AN D, IN C. , Br emen, AL US A
Light Duty S ystem
for Small Inlets
4501-5081
POWERTRAK
POWERTRAK
Jr.
Jr.
