Hired-Hand Emergency Back-Up and Alarms: Farm Hand Back Up System User Manual
Page 13
4801-5048
Farm Hand ST
12
9.2
Connecting Stages To Farm Hand Back Up (Double Pole)
AC Power
Stage 1
Stage 2
Stage 3
Stage 4
IN OUT
IN OUT
IN OUT
IN OUT
Sensor 1
Sensor 2
Blk Wht Shld Wht Blk
Temp. Sensors
Stage 4
Stage 3
NO NC Com NO NC Com
Stage 2
Stage 1
NO NC Com NO NC Com
INSET 1
INSET 2
INSET 1
INSET 2
Hot
Neutral
Hot
Neutral
Breaker
Panel
Cooling
Heating
Breaker
Panel
Farm Hand 12 Stage Relay Panel
