Specifications
47
8.0
Specifications
Pressure Specifications:
Pressure range:
Three independent pressure ranges
per instrument. See Section 5.0 on
page 44 for available ranges.
Available pressure
calibrations:
Gage only or absolute only,
Overall accuracy:
< ±0.05% Full Scale Max. Accuracy
statement includes all effects of
linearity, hysteresis, repeatability and
ambient temperature
Operating Temp:
+40° to +122°F (+4.4° to +50.0° C)
Storage Temperature: 0° to +185° F (–17.8° to +85°C)
Pressure Media:
Dry gaseous nitrogen, standard
External Pressure Cylinder, UPC5200 only:
Capacity:
83.3 ft
3
N
2
@ 2,216 PSIG
Volume:
960 in
3
Rating:
2,216 psig
Test Pressure:
3,694 psig
Material:
Aluminum
Regulated Pressure Gage:
Size:
2-1/2 in. diameter
Range:
5K model 0–600 PSIG,
10K model 0–3,000 PSIG
Test Pressure:
5K model 900 PSIG,
10K model 4,500 PSIG
Accumulator Gage:
Size:
2-1/2 in. diameter
Range:
5K model 0–6,000 PSIG,
10K model 0–15,000 PSIG
Test Pressure:
5K model 9,000 PSIG,
10K model 22,500 PSIG
Over-pressure Rupture Disk:
Rating:
3,000 PSIG, nominal
Type:
Stainless steel outer case
Pressure Media Filter:
Rating:
20 microns, Test Port and Input Port
40 microns, Test Port Hose
Type:
Field replaceable
ORION-3A Control Valve:
Type:
Micro-metering with replaceable soft
seat
Material:
Aluminum knobs, black anodized
All other parts 300 series stainless
steel
Relief Valve:
Type:
Adjustable, atmospheric bleed
Setting:
Adjustable, set between 525-550
PSIG
Material:
300 series Stainless Steel.
Internal Piping:
Tubing:
1/8 in. O.D., 0.035 in. wall thickness,
seamless Cu.
1/4 in. O.D., 0.035 and 0.065 in. wall
thickness, seamless 304 Stainless
Steel
Couplings:
Stainless Steel, Swagelok type
Input Port:
Style:
1/4" 37° AN flare male
Pressure Rating:
2216 PSIG connected
Material:
300 series Stainless Steel
Test Port:
Pressure Rating:
10,000 PSIG.
Material:
300 series Stainless Steel
Vent Port:
Style:
1/4" 37° AN male
Pressure Rating:
10,000 PSIG
Material:
300 series Stainless Steel
Pressure Hoses:
Quantity Supplied:
Two; one input, one output
Length:
4 ft. nominal, input hose
5 ft. nominal, output hose
Style:
Input hose - Nylon-lined core tube
with synthetic fiber braid and polyester
cover. Fitted with CGA-580 (Brass)
nipple fitting on one end and 1/4" 37˚
female AN swivel pressure fitting on
opposite end.
Output hose - Nylon-lined core tube
with synthetic fiber braid and
polyurethane cover. Fitted with
quick-disconnect plug (St Stl) on one
end and 1/4" 37˚ female AN swivel
tube coupling on the other.
Regulator:
Type:
Single stage, self-venting, non-bleed
Pressure Rating:
3,000 PSIG max. inlet
Internal Pressure Sensor:
Type:
Bonded, metal foil strain gage,
sputtered thin-film or equivalent.
Sensitivity:
3 mV/V nominal.
Construction:
Completely weld-sealed Stainless
Steel
outer body and pressure
cavity.
Carrying Case UPC5200 only:
Type:
Aluminum case with latched cover and
handle
Material thickness:
0.090 in., nominal
Finish:
Enamel paint, textured finish
Color:
Gray
