34

UPC5200/UPC5210 Operation and Maintenance Manual

4.3

ORION-3A Valve Assembly (55287) Parts List

The following table lists the component parts of the ORION-3A.

Ref Number

PN

Description

Quantity

1

57482

Nut, valve needle housing

2

2

54401

Locknut

2

3

58079

Knob

2

4

57889

Knob, insert

2

5

57256

Gear, spur 40 teeth

2

6

59233

Gear, spur 18-tooth

2

7

55896

Valve Seat

4

8

59387

Valve Seat, stem

4

9

59045

Valve, needle seat

4

10

54540

Housing, valve needle

2

11

59551

Valve Needle

2

12

57600

Bushing, end

1

13

58554

Cap, end

1

14

58699

Shaft

1

15

58597

Piston

1

16

59309

Body, dual valve

1

17

57580

Knob

1

18

55533

Valve Needle

2

19

55159

Housing, valve needle

2

20

56784

Locknut,9/16-18UNF-3A, SST

1

21

58464

Setscrew,12-24NCx1/4 SST

14

22

58308

Ball, Tungsten Carbide

14

23

59383

Setscrew, 6-32NCx1/8 SST

4

24

58342

Screw, cap hex socket head, #2-56UNC-3A

6

25

59322

Setscrew, 6-32NCx1/4 SST

6

26

59326

Setscrew, 2-56NCx1/8, alloy steel

4

27

55569

O-ring, Fluorocarbon (Viton) color black w/white dot

5

28

55552

O-ring, Fluorocarbon (Viton) color black w/white dot

4

29

58090

O-ring, Fluorocarbon (Viton) color black w/white dot

1

30

60633

Retainer, Packing Backup

4

31

55570

Washer, backing

4

32

58045

O-ring, Fluorocarbon (Viton) color black w/white dot

1

33

59245

Washer, nylon

2

34

60202

Setscrew, hex

2

35

60837

Screw, MACH #10- 32NF SST

2

36

54905

Screw, self sealing

1

38

57027 Washer,

backup

1

39

54448

Retainer, packing backup

1

40

55615

O-ring, Fluorocarbon (Viton) color black w/white dot

1

41

58314

Ball, chrome, steel

32

42

59731

Male connector, 1/8 tube x 1/8 NPT, stainless steel

3

Table 4-2. ORION-3A Valve Assembly Parts List
